Strict Low-SWaP Constraints
UAVs have very limited space, power, and payload. The antenna must deliver high
performance in a small footprint.
UAV & Drones
High-reliability GNSS antenna systems engineered for aerial platforms requiring stable positioning under severe airframe vibration, rapid attitude variations, and complex onboard EMI.
HelioNavi delivers precision-engineered UAV antenna technology, ranging from full-constellation, multi-frequency Helix and Patch arrays to advanced anti-jamming solutions. By maintaining sub-millimeter phase center stability and multi-stage out-of-band filtering, our GNSS antennas guarantee reliable signal tracking and rapid RTK initialization despite severe airframe vibrations and rapid attitude shifts. These high-performance GNSS antennas provide centimeter-level accuracy for mission-critical operations, including high-precision aerial surveying & LiDAR mapping, precision agriculture, environmental monitoring, industrial inspections, and emergency disaster relief.
UAV GNSS Performance Is Difficult in Real Applications
GNSS antenna performance in UAV systems is defined by complex operating environments rather than static datasheet specifications.
Dynamic Flight Attitude Variation
Vibration, rolling maneuvers, and attitude changes cause signal fluctuation and
phase center shifts.
RF Coexistence Environment
Telemetry, video link, LTE/5G modules, and cameras increase noise floor and
interference.
Low-Elevation Tracking Instability
Multipath and signal blockage are more severe at low elevation, impacting RTK
positioning reliability.
Core Engineering Capabilities
15+Years
GNSS Antenna R&D and Engineering Experience
500+Platforms
Successful GNSS Integrations Across Global UAV & Drone OEMs
Sub-Millimeter
Phase Center Consistency Under Ruggedized Vibration Environments
Full-Constellation Tracking
Multi-frequency tracking across GPS, GLONASS, Galileo, BeiDou, QZSS, and SBAS for robust positioning in demanding flight environments.
Optimized Low-SWaP
Ultra-compact, lightweight antenna designs with low power consumption for space- and energy-constrained UAVs.
Phase Center Stability
Stable phase center and low variation under vibration, temperature, and dynamic flight motion.
Bespoke RF Integration
Custom RF tuning, cable routing, and mechanical integration for optimal onboard performance in complex UAV environments.
01
High-Precision Positioning Antennas (Helix & Patch)
- Helix and patch antennas for high-accuracy positioning
- Excellent multipath rejection and wide bandwidth
- External and embedded options for flexible integration
02
Multi-Functional Combo Antennas (GNSS + Communication)
- Integrated GNSS with 4G/5G, Wi-Fi, or telemetry antennas
- Optimized isolation and RF performance
- Reduces system complexity and saves integration space
03
Smart Integrated GNSS Antennas (Antenna + GNSS Receiver)
- Integrated antenna and GNSS receiver for compact systems
- High-precision RTK solution reduces wiring and weight
- Plug-and-play performance with easy integration
Applications of Typical UAV Missions
High-Precision Mapping & Survey
Long-Endurance VTOL & Fixed-Wing Inspection
Autonomous Industrial Surveillance Drones
Precision Agriculture UAVs
Powerline Inspection
High-Dynamic Drone Light Shows & Swarm
UAV Antenna Integration Technical Support
HelioNavi provides engineering-level support for UAV GNSS antenna selection and integration.
- UAV platform type and flight dynamics
- GNSS frequency band requirements
- Installation position and ground plane conditions
- RF interference and coexistence environment
- RTK accuracy requirements
